2026 Yanmar TL75VP
Get in Touch
Description
2026 Yanmar TL75VP
Built to Lift Productivity
The TL75VP pairs the versatility of a vertical-lift design with the ride quality of our ASV Posi-Track® undercarriage. With a strong rated operating capacity and excellent reach at full lift height, it is built for pallet work, truck loading and demanding material handling. Dependable traction and low ground pressure help keep it working confidently across a wide range of surfaces.
Built to Lift. Built to Last.
Whether you’re loading trucks, handling pallets or moving material across difficult terrain, the TL75VP is ready to work. Its vertical-lift geometry delivers strong lifting performance and reach throughout the lift cycle, while the ASV Posi-Track® fully suspended torsion-axle undercarriage provides exceptional traction, flotation and stability. Add customizable electrohydraulic controls, enhanced visibility and standard SmartAssist Remote telematics, and you have a machine built for long days, demanding work and lasting performance.
Features May Include:
Go Higher. Move More.
- The TL75VP delivers the lift height, reach and control needed for demanding material-handling work. Its vertical-lift design delivers strong reach at full lift height, while customizable electrohydraulic controls help operators place loads more confidently.
Traction That Doesn’t Back Down
- The ASV Posi-Track® undercarriage puts more track on the ground, delivering the traction, flotation and stability to work confidently across soft, uneven and challenging terrain. Standard 15-inch wide tracks let you equip the TL75VP for the ground conditions you face every day.
Visibility Meets Intelligence
- A standard rearview camera and available LED side lights and clear side glass provide greater visibility of the work around you. Adjustable armrests support comfortable, confident operation, while SmartAssist Remote telematics keeps important machine information close at hand, helping you manage maintenance, utilization and uptime.
Info
Industry
Agriculture
Make
Yanmar
Model
TL75VP
Trim
Base
Year
2026
MSRP
N/A
Category
Loader
Subcategory
Compact Track
Specs
Warranty
2 year
Weight
7,915 lbs. | Operating (Open ROPS): 7,915 lbs. | Operating (Enclosed Cab): 8,355 lbs. | Ground Pressure: 4.5 psi | Tipping: 6,571 lbs.
Power/Horsepower
71.5 HP
Notes
ROC: 2,300 lbs. | Loader Arms: Vertical | Travel Speed, Maximum: 9.1 mph | Auxiliary Hyd. Flow, Standard: 21.4 gpm | Auxiliary Hyd. Flow, High: 26.7 gpm | Auxiliary Hyd. Pressure, Standard: 3,481 psi | Auxiliary Hyd. Pressure, High: 3,771 psi | Controls: Variable flow via joystick rocker switch, or continuous via console switch. | Couplers (Flat Faced Couplers): 1/2 in. | Quick-Attach Mounting Plate: Universal standard skid steer quick attach coupler with manual or hydraulic latching pins | Emission Controls: Meets all U.S. EPA Tier 4 final standards | Undercarriage: General purpose track constructed of rubber compound with embedded co-polymer cords and all-purpose treads | Nominal Charge: 12 V | Charging System: 80 amp alternator | Outlets: 1-12 V port inside operator station | Wiring: Pre-wired for all factory-available accessories | Cab: Open Rops Base, Open Rops Premium Plus Hydraulics, All Weather Cab Premium, All Weather Cab Pemium Plus Hydraulics, Forestry | Controls: Electronic joystick controls with ISO or H pattern settings, adjustable operator profiles and speeds | Machine Display: Multi-functional color 7 inch display/indicator: Engine RPM, engine coolant temperature, engine oil pressure, hydraulic oil temperature, battery voltage, hour meter, fuel level, trip meter, engine diagnostics, system monitoring, fault logging, integrated rear view camera, password protection with user profiles, job clock, maintenance schedules
Fuel Capacity
21.4 gal. | Rated Operating (35% of Tipping Weight): 2,300 lbs. | Operating (50% of Tipping Weight): 3,286 lbs.
Fuel System
Cooling: High efficiency side-by-side radiator and oil cooler, not stacked
Engine Type
Diesel, 4-cylinder, turbocharged
Fuel Type
Diesel
Displacement
128.1 cu in
Torque
193.8 ft-lb
Family/Type
Cooling and Capacity: Belt-driven fan and anti-freeze filled radiator cooling
Air Filter (Cabin)
Intake Cleaner: Dual stage
Width
Track: 15 in.
Length
Of Track on Ground: 59 in.
Ground Clearance
Contact Area: 1,770 in.
Drivetrain
System: Direct drive hydrostatic pumps powering two direct drive sprocket motors controlled by selectable electronic ISO/H-pattern joysticks
Wheels
Roller: 12 ultra-high molecular weight polyethylene and rubber wheels per track, wheels include metal-face sealed bearings
Battery
800 CCA
Seats
Standard mechanical suspension seat, single sided lap bar and 2 in. wide seat belt
