2026 Yanmar TL65RS-1C
Agile Power for Tight Spaces
Introducing the TL65RS-1C, Yanmar’s compact track loader that’s as rugged as they come yet meticulously designed. This machine unites brute force with rare finesse, offering a perfect balance for tackling a myriad of tasks. Under its hood roars a 67-horsepower Yanmar engine, ready to take on the toughest terrains and heaviest loads without breaking a sweat.
Compact Power, Maximum Versatility
From maneuvering through cramped corners to lifting heavy loads with ease, the TL65RS-1C doesn’t just get the job done, it excels at it. Its rugged exterior hints at the resilience under the hood, making it a dependable companion for every project, no matter the challenge. So, if you’re looking for a compact track loader that doesn’t compromise on power or performance, the TL65RS-1C is your ultimate choice.
Features May Include:
Premium Comfort and Visibility
- Step into the TL65RS-1C’s cab, your command center encased in comfort and practicality. The suspended seat keeps you cruising in comfort, while the touchscreen and panoramic view keep you in control. And there’s a removable roof hatch for quick escapes when the going gets rough. It’s not just a workspace; it’s your cockpit for mastering every task.
Built for Endurance and Dependability
- Count on the TL65RS-1C’s rugged reliability, from its steel-embedded undercarriage to heavy-duty tracks. Featuring easy service access, it’s built to take a beating and keep going. No downtime, no compromises. Just relentless performance when you need it most.
Enhanced Control
- Level up your operator game with the TL65RS-1C’s cutting-edge 7-inch color display and preset options for attachment angles and loader arm positions. Its rugged Dual Direction Self Leveling and Automatic Ride Control features make for seamless shifting between low and high-speed modes.
Info
Industry
Agriculture
Make
Yanmar
Model
TL65RS-1C
Trim
Base
Year
2026
MSRP
N/A
Category
Loader
Subcategory
Compact Track
Specs
Weight
8,575 lbs. | Operating (Open ROPS Base): 8,575 lbs. | Operating (AWC Cab Base): 8,915 lbs. | Ground Pressure: 5.7 psi
Power/Horsepower
67 HP
Notes
ROC: 2,100 lbs. | Loader Arms: Vertical | Travel Speed, Maximum: 7.5 mph | Emission Controls: Meets all U.S. EPA Tier 4 final standards | Undercarriage Suspension: Two independent torsion axles per undercarriage | Max System Pressure, Low / High: 3,480 / 3,771 psi | Controls: Intermittent via joystick button or continuous via console switch. High flow is adjustable. | Couplers (Flat Faced Couplers): 1/2 in. | Nominal Charge: 12 V | Charging System: 80 amp alternator | Outlets: 1-12 V port inside operator station | Wiring: Pre-wired for all factory-available accessories | Cab: ROPS or All-Weather Cab with curved glass door | 7-in. Color Machine Display: Fuel, tachometer, engine temp, hour meter, battery, trip meter, hydraulic temperature, water temperature, multiple languages | ROPS: ROPS: ISO 3471 Restraint-ISO 6683, SAE J2292, Cal OSHA 1596 | FOPS: ISO 3449 Level 1(level 2 optional), emergency roof exit | Illumination: 2 – Forward-facing LED lights 2 – Rear-facing LED lights
Load Capacity
Tipping: 7,300 lbs.
Fuel Type
Diesel
Fuel Capacity
21.4 gal. | Rated Operating: 2,100 lbs. | Pump: 21.4 / 26.7 gpm
Engine
Speed: Standard hand dial operation with foot pedal optional
Torque
193.8 ft-lb
Length
Of Track on Ground: 60 in.
Ground Clearance
Contact Area: 1,512 in.
Width
Track: 12.6 in.
Drivetrain
System: Two hydrostatic direct drive sprockets controlled by single joystick
Displacement
2.1 L
Fuel System
Cooling: High efficiency side-by-side radiator and oil cooler
Engine Type
Diesel 4-cylinder, Intercooled Turbo
Battery
800 CCA
Warranty
2 year
Seats
Mechanical suspension seat with 2-in. seat belt
Air Filter (Cabin)
Intake Cleaner: Dual-stage
