    2026 Yanmar TL65RS-1C

    Agile Power for Tight Spaces
    Introducing the TL65RS-1C, Yanmar’s compact track loader that’s as rugged as they come yet meticulously designed. This machine unites brute force with rare finesse, offering a perfect balance for tackling a myriad of tasks. Under its hood roars a 67-horsepower Yanmar engine, ready to take on the toughest terrains and heaviest loads without breaking a sweat.

    Compact Power, Maximum Versatility
    From maneuvering through cramped corners to lifting heavy loads with ease, the TL65RS-1C doesn’t just get the job done, it excels at it. Its rugged exterior hints at the resilience under the hood, making it a dependable companion for every project, no matter the challenge. So, if you’re looking for a compact track loader that doesn’t compromise on power or performance, the TL65RS-1C is your ultimate choice.

    Features May Include:

    Premium Comfort and Visibility

    • Step into the TL65RS-1C’s cab, your command center encased in comfort and practicality. The suspended seat keeps you cruising in comfort, while the touchscreen and panoramic view keep you in control. And there’s a removable roof hatch for quick escapes when the going gets rough. It’s not just a workspace; it’s your cockpit for mastering every task.

    Built for Endurance and Dependability

    • Count on the TL65RS-1C’s rugged reliability, from its steel-embedded undercarriage to heavy-duty tracks. Featuring easy service access, it’s built to take a beating and keep going. No downtime, no compromises. Just relentless performance when you need it most.

    Enhanced Control

    • Level up your operator game with the TL65RS-1C’s cutting-edge 7-inch color display and preset options for attachment angles and loader arm positions. Its rugged Dual Direction Self Leveling and Automatic Ride Control features make for seamless shifting between low and high-speed modes.

    Info

    Industry

    Agriculture

    Make

    Yanmar

    Model

    TL65RS-1C

    Trim

    Base

    Year

    2026

    MSRP

    N/A

    Category

    Loader

    Subcategory

    Compact Track


    Specs

    Weight

    8,575 lbs. | Operating (Open ROPS Base): 8,575 lbs. | Operating (AWC Cab Base): 8,915 lbs. | Ground Pressure: 5.7 psi

    Power/Horsepower

    67 HP

    Notes

    ROC: 2,100 lbs. | Loader Arms: Vertical | Travel Speed, Maximum: 7.5 mph | Emission Controls: Meets all U.S. EPA Tier 4 final standards | Undercarriage Suspension: Two independent torsion axles per undercarriage | Max System Pressure, Low / High: 3,480 / 3,771 psi | Controls: Intermittent via joystick button or continuous via console switch. High flow is adjustable. | Couplers (Flat Faced Couplers): 1/2 in. | Nominal Charge: 12 V | Charging System: 80 amp alternator | Outlets: 1-12 V port inside operator station | Wiring: Pre-wired for all factory-available accessories | Cab: ROPS or All-Weather Cab with curved glass door | 7-in. Color Machine Display: Fuel, tachometer, engine temp, hour meter, battery, trip meter, hydraulic temperature, water temperature, multiple languages | ROPS: ROPS: ISO 3471 Restraint-ISO 6683, SAE J2292, Cal OSHA 1596 | FOPS: ISO 3449 Level 1(level 2 optional), emergency roof exit | Illumination: 2 – Forward-facing LED lights 2 – Rear-facing LED lights

    Load Capacity

    Tipping: 7,300 lbs.

    Fuel Type

    Diesel

    Fuel Capacity

    21.4 gal. | Rated Operating: 2,100 lbs. | Pump: 21.4 / 26.7 gpm

    Engine

    Speed: Standard hand dial operation with foot pedal optional

    Torque

    193.8 ft-lb

    Length

    Of Track on Ground: 60 in.

    Ground Clearance

    Contact Area: 1,512 in.

    Width

    Track: 12.6 in.

    Drivetrain

    System: Two hydrostatic direct drive sprockets controlled by single joystick

    Displacement

    2.1 L

    Fuel System

    Cooling: High efficiency side-by-side radiator and oil cooler

    Engine Type

    Diesel 4-cylinder, Intercooled Turbo

    Battery

    800 CCA

    Warranty

    2 year

    Seats

    Mechanical suspension seat with 2-in. seat belt

    Air Filter (Cabin)

    Intake Cleaner: Dual-stage
