2026 Yanmar TL65RP
Get in Touch
Description
2026 Yanmar TL65RP
Compact Performance. Big Capability.
The TL65RP delivers the agility needed for confined jobsites without sacrificing productivity. Built on our ASV Posi-Track® fully suspended torsion-axle undercarriage, it provides exceptional traction, low ground pressure and a smooth ride across soft, uneven and challenging terrain. From landscaping and property maintenance to rental and construction, the TL65RP offers the capability and maneuverability to keep work moving.
Capability Without Compromise
With 67.1 horsepower, a 2,000-pound rated operating capacity and available high-flow hydraulics, the TL65RP is ready for demanding construction and landscaping applications. Its radial-lift path excels at digging, grading and loading at lower heights. High ground clearance and the ASV Posi-Track® undercarriage provide sure-footed performance across difficult terrain, while the comfortable cab and intuitive controls help operators stay productive throughout the day.
Features May Include:
More Power Where it Counts
- The TL65RP puts its power to work with strong breakout performance for digging, grading and pushing. Available high-flow hydraulics provide the added capability to operate demanding attachments.
Confidence From the Ground Up
- The ASV Posi-Track® undercarriage provides exceptional traction and flotation with a smooth, stable ride. High ground clearance helps the TL65RP travel confidently over challenging terrain, and standard 15-inch wide tracks allow the machine to be matched to the work ahead.
Command the Job in Comfort
- A suspended seat and adjustable armrests create a comfortable operating position, while customizable electrohydraulic controls make machine functions feel natural and precise. A standard rearview camera and available LED side lights and clear side glass provide greater visibility of the work around you. SmartAssist Remote telematics helps owners stay connected to important machine information and comes standard.
Info
Industry
Agriculture
Make
Yanmar
Model
TL65RP
Trim
Base
Year
2026
MSRP
N/A
Category
Loader
Subcategory
Compact Track
Specs
Warranty
2 year
Weight
7,405 lbs. | Operating (Open ROPS): 7,405 lbs. | Operating (Enclosed Cab): 7,845 lbs. | Ground Pressure: 4.2 psi | Tipping: 5,714 lbs.
Power/Horsepower
67.1 HP
Notes
ROC: 2,000 lbs. | Loader Arms: Radial | Travel Speed, Maximum: 9.1 mph | Auxiliary Hyd. Flow, Standard: 21.4 gpm | Auxiliary Hyd. Flow, High: 26.7 gpm | Auxiliary Hyd. Pressure, Standard: 3,481 psi | Auxiliary Hyd. Pressure, High: 3,771 psi | Controls: Variable flow via joystick rocker switch, or continuous via console switch. | Couplers (Flat Faced Couplers): 1/2 in. | Quick-Attach Mounting Plate: Universal standard skid steer quick attach coupler with manual or hydraulic latching pins | Emission Controls: Meets all U.S. EPA Tier 4 final standards | Undercarriage: General purpose track constructed of rubber compound with embedded co-polymer cords and all-purpose treads | Nominal Charge: 12 V | Charging System: 80 amp alternator | Outlets: 1-12 V port inside operator station | Wiring: Pre-wired for all factory-available accessories | Cab: Open Rops Base, Open Rops Premium Plus Hydraulics, All Weather Cab Premium, All Weather Cab Pemium Plus Hydraulics, Forestry | Controls: Electronic joystick controls with ISO or H pattern settings, adjustable operator profiles and speeds | Machine Display: Multi-functional color 7 inch display/indicator: Engine RPM, engine coolant temperature, engine oil pressure, hydraulic oil temperature, battery voltage, hour meter, fuel level, trip meter, engine diagnostics, system monitoring, fault logging, integrated rear view camera, password protection with user profiles, job clock, maintenance schedules
Fuel Capacity
21.4 gal. | Rated Operating (35% of Tipping Weight): 2,000 lbs. | Operating (50% of Tipping Weight): 2,857 lbs.
Fuel System
Cooling: High efficiency side-by-side radiator and oil cooler, not stacked
Engine Type
Diesel, 4-cylinder, turbocharged
Fuel Type
Diesel
Displacement
128.1 cu in
Torque
193.8 ft-lb
Family/Type
Cooling and Capacity: Belt-driven fan and anti-freeze filled radiator cooling
Air Filter (Cabin)
Intake Cleaner: Dual stage
Width
Track: 15 in.
Length
Of Track on Ground: 59 in.
Ground Clearance
Contact Area: 1,770 in.
Drivetrain
System: Direct drive hydrostatic pumps powering two direct drive sprocket motors controlled by selectable electronic ISO/H-pattern joysticks
Wheels
Roller: 12 ultra-high molecular weight polyethylene and rubber wheels per track, wheels include metal-face sealed bearings
Battery
800 CCA
Seats
Standard mechanical suspension seat, single sided lap bar and 2 in. wide seat belt
