2026 ASV RT-40
Get in Touch
Description
2026 ASV RT-40
RT-40 Compact Track Loader
Works Hard, Plays Harder
ASV offers an ever-expanding lineup of purpose-built accessories for brush cutting, mulching, land clearing and other heavy-duty applications.
Exceptional power and performance come standard
With a compact frame and maximum power, the RT-40 provides a productive alternative to walk-behind and stand-on mini skid-steer loaders. And with its reliability, serviceability and comfort it’s ideal for homeowners and contractors looking to accomplish a lot in small spaces.
Features May Include:
From Top to Bottom, We Go Above and Beyond
Power
- Built for performance, this 4’ wide powerhouse features a turbocharged YANMAR diesel powerplant. The 1.6-liter displacement engine produces 93.6 foot-pounds of torque while providing high tractive effort as a result of ASV’s Posi-Power system—this allows for exceptional pushing and digging power. The 4,005-pound RT-40 features a rated operating capacity of 931 pounds and a tipping load of 2,660 pounds.
Performance
- The ASV RT-40 compact track loader is engineered to deliver minimal ground pressure while topping out at 7.1MPH and reaching an impressive 8.4-foot lift height. The machine’s frame allows for a 10.8-inch ground clearance thoroughly outperforming any walk-behind or stand-on loader when it comes to traveling obstructed terrain.
Comfort
- To give operators peace of mind, we designed the RT-40 with premium safety, comfort, and visibility features. The seated cab eliminates the fatigue from standing all day and offers protection from the elements. It’s built to provide ample headroom for taller operators and it’s pressurized for a clean, comfortable environment. Large windows also make it easy for operators to be aware of their surroundings.
Serviceability
- For maximum serviceability, the RT-40 is designed with a large rear-tilting hood to provide easy access to all maintenance points, including filters, oil and fuel tanks, reservoirs, hydraulic and water separator drains, and the battery. Servicing improvements within the cab include placing the fuse panel there for fast access, as well as making the seat removable with just two bolts. All of these features mean less downtime spent servicing the machine and more time operating it.
Info
Industry
Agriculture
Make
ASV
Model
RT-40
Trim
Base
Year
2026
MSRP
N/A
Category
Track Loader
Subcategory
Compact
Specs
Load Capacity
Rated Operating Capacity @ 35%: 931 lbs | Rated Operating Capacity @ 50%: 1330 lbs | Tipping Load: 2660 lbs
Fuel Type
Diesel
Cylinders
3-cylinder
Torque
Torque Peak: 93.6 ft-lb
Steering
Loader Control: Right-hand pilot hydraulic joystick controls loader lift/tilt, with intermittent control of auxiliary hydraulics | Drive Control: Left-hand pilot hydraulic joystick controls machine speed and direction
Oil Capacity
Engine Oil (Including Filter): 6 quarts | Hydraulic Tank: 3.4 gal | Engine Coolant: 1.8 gal
Length
Full Length: 112.7 in | Length of Track on the Ground: 55 in
Ground Clearance
10.8 in
Brakes
Parking Brake: Actuated by dash-mounted switch
Alternator
Charging System: 80 Amp Alternator
Interior
Multi-Functional Color 4.3 Inch Display/Indicator: Engine RPM, Engine Coolant Temperature, Engine Oil Pressure, Hydraulic Oil Temperature, Battery Voltage, Hour Meter, Fuel Level, Trip Meter, Engine Diagnostics, System Monitoring, Fault Logging and More | Outlets/Convenience: 1-12 V port inside operator station / 1 - 12 V power ports | Standard Features: Horn, backup alarm, rear window | ROPS Meets ISO 3471 | FOPS Meets ISO 3449 | Operator Restraint Anchorage Meets ISO 6683, CAL OSHA 1596
Notes
Ground Pressure: 3.3 psi | Ground Contact area: 1210 in2 | Pump Capacity: 13.3 gpm | System Pressure, Max: 3000 psi | Auxiliary Hydraulic Controls: Variable flow via joystick button or continuous via console switch, mode selectable via dash-mounted switch | Couplers: Push to connect quick couplers mounted on manifold block. Pressure relief valve on block
Family/Type
Compact track loader
Fuel Capacity
13 gal
Engine
YANMAR 3TNV86CT
Displacement
95.7 in3
Drivetrain
Drive System: Two hydrostatic direct drive sprockets controlled by a single joystick | Track Drive Sprocket: Elevated with low friction, replaceable sprocket rollers | Undercarriage suspension: 2 independent torsion axles per undercarriage
Width
48.3 in | Track Width: 11 in
Wheels
Roller Wheels: 12 high-density polyurethane and rubber wheels per track. Wheels include sealed bearings | Roller Wheel Diameter: 10 in
Electrical
Nominal Charge: 12V | Illumination: 2 - Fixed forward-facing LED lights, 1 - Adjustable rear-facing LED light, 1 - Interior light, 2 - Red LED tail lights | Wiring: Pre-wired for all factory-available accessories
Starter
Engine block heater
Seats
Adjustable contour vinyl seat with built-in operator presence switch, lap bar and 2 in wide seat belt
Style
Loader Arms: Radial
Engine Type
Diesel, 3-cylinder, turbo charged | Cooling System: High efficiency oil cooler beside engine radiator, not stacked
Power/Horsepower
Engine Power: 38.2 hp | Gross Horsepower: 38.2 hp
Transmission
Max. Travel Speed: 7.1 mph
Throttle
Engine speed: Hand-operated rotary throttle
Height
Hinge Pin Height: 101 in | Machine Height: 75.5 in.
Weight
Operating Weight: 4005 lbs
Tires
Track Type: General purpose track constructed of rubber compound with embedded co-polymer cords and all-purpose treads. Single row of track drive lugs molded in. Turf track with smooth tread available as an option
Battery
590 CCA
PTO Type
Standard Features: Manual quick-attach
